MD-130 Medical Tablet
A 13.3-inch medical Windows tablet for imaging review, cart-based workflows and equipment control. A fanless Core i5 platform, high-capacity battery and configurable medical-imaging I/O support diagnostic and bedside applications.
Deployment Capabilities
Expanded viewing area
The 13.3-inch Full HD display provides space for records, controls and image-oriented applications.
Established Windows software
The x86 platform can host compatible clinical, instrument and imaging applications.
Cart and portable operation
The form factor, battery and kickstand support movement between work areas and cart-based use.
Configurable peripheral integration
Wireless, reader, docking and imaging-interface options can be selected for the intended system.
Technical Features
Larger viewing area
A 13-inch class display improves dashboards, records and diagnostic image viewing. More information can remain visible at once, reducing repeated scrolling during clinical work.
Windows software fit
The x86 platform supports established clinical and instrument software. This supports established hospital applications, device utilities and specialised imaging software.
Medical configuration
Medical safety and EMC configuration is available according to selected model. The platform can be integrated into systems that require medical electrical safety and EMC compliance.
Mobile deployment
The form factor suits carts, rounds and portable diagnostic workflows. Its screen size is large enough for detailed work while remaining movable between care areas.
Peripheral integration
Reader, wireless and docking options can be configured for the application. These options support patient identification, external instruments and cart-based operation.
Project configuration
Processor, memory, storage and accessory options support different medical workflows. The platform can therefore serve documentation, imaging, telemedicine or equipment-control roles.
Specifications
| Parameter | Unit | Value / Description |
|---|---|---|
| COMPUTE & DISPLAY | ||
| Display | inch | 13.3 IPS. |
| Resolution | pixels | 1920 × 1080. |
| Brightness | nit | 400. |
| Processor | — | Intel Tiger Lake Core i5-1135G7. |
| Graphics | — | Intel Iris Xe Graphics. |
| Operating system | — | Windows 11 Pro or Windows IoT. |
| Cooling | — | Fanless. |
| Memory / storage | — | 16 GB LPDDR4X and 256 GB NVMe Gen4 baseline; storage expansion options by configuration. |
| MEDICAL & RUGGEDNESS | ||
| Medical certification | — | IEC 60601-1 and IEC 60601-1-2. |
| Ingress protection | — | IP54. |
| Touch | — | 10-point capacitive touch with glove and wet-touch support. |
| Mechanical | — | 180° kickstand that also functions as a carry handle. |
| POWER & INTEGRATION | ||
| Battery | Wh | 66.3. |
| Imaging I/O | — | Customisable interfaces for X-ray, ultrasound and endoscopy systems. |
| Mounting | — | Portable, cart and equipment-integration use. |
| Application areas | — | Medical imaging, diagnostic equipment and mobile clinical workstations. |
IEC 60601 references apply to certified product variants and the specified medical power system.
Applications
Clinical documentation
Use the 13.3-inch display for records, order entry and detailed clinical workflows. The larger screen supports more information without relying on a fixed workstation.
Medical carts
Integrate Windows compute, display and wireless access into mobile treatment or diagnostic carts. The kickstand and carry-handle design also supports portable use away from the cart.
Imaging review
Display diagnostic, procedural and camera images on a Full HD screen with Intel graphics. The format is suited to review and guidance rather than pocket-style mobility.
Telemedicine
Combine video communication, documentation and peripheral connectivity in a larger mobile interface. This suits consultation rooms, outreach projects and mobile clinics.
Bedside systems
Provide access to hospital applications and connected devices at the bedside. Glove and wet-touch support can improve operation in demanding care environments.
Medical OEM
Use the fanless Windows platform as the integrated user interface for specialised medical equipment. Storage, connectivity and imaging I/O can support application-specific system designs.
