SAG 410 Series Solid Aerosol / Dust Disperser
Modular solid-particle disperser family using controlled dosing mechanisms for reproducible dust and powder aerosol generation across filter, separator and sensor test applications.
Model Overview
| Model | Group | Positioning | Core fit |
|---|---|---|---|
| SAG 410 Series | Modular solid-aerosol disperser family | Controlled dosing and compressed-air dispersion of powders using variant-specific belt or annular-gap feed systems | Filter dust loading, separator testing, sensor evaluation and laboratory solid-aerosol research |
Key Features
Variant-specific dosing
Different SAG 410 configurations cover a broad range of powder properties and mass-feed requirements.
Reproducible material feed
Controlled dosing separates powder delivery from the dispersion-air setting.
Modular test-system integration
Connects to ducts, dilution stages and particle-measurement instruments as required.
Wide application range
Supports standard test dusts and compatible non-hazardous powders selected for the method.
Technical Specifications
| Parameter | Unit | Value / Description |
|---|---|---|
| SOLID AEROSOL GENERATION | ||
| Instrument family | — | SAG 410 series |
| Dosing principle | — | Variant-specific precision belt or annular-gap dosing |
| Dispersion principle | — | Compressed-air deagglomeration and transport |
| Test material | — | Compatible standard dusts and powders |
| Mass-flow range | — | Variant and material dependent |
| INTEGRATION | ||
| Carrier gas | — | Dry compressed air |
| Downstream modules | — | Duct, dilution, sampling and particle measurement as required |
| Material review | — | Powder flow, abrasion, toxicity and explosion risk must be assessed for each application |
Values shown are manufacturer specifications for model selection. Confirm the final configuration, accessories, utilities and calibration scope before ordering.
Applications
Controlled test-dust feed
Supplies standard dust for loading, lifetime and dust-holding-capacity measurements.
Solid-particle challenge aerosol
Generates reproducible dust aerosol for cyclones, separators and filtration components.
Particle challenge for dust sensors
Supports response and durability studies of particulate sensors and monitors.
Configurable powder dispersion
Provides a modular platform for laboratory studies using compatible dry powders.
